Neoprene Headcap
The Neoprene Headcap is a comfortable, reliable and flexible solution to place electrodes for EEG monitoring and tES stimulation. Its positioning grid with 39 predefined and clearly annotated positions is based on a subset of the international 10-20 EEG system. Extra positions can be created using the neoprene punchtool. The cap is available in four adult-sized models (XL, L, M, S). Two extra kid-sized models (K, KS) can be acquired with the Kid Neoprene Cap.
Materials and sizes
· Material: Neoprene
· Sizes (cranial perimiter): S (49cm), M (54cm), L (57cm), XL (60cm)
Positioning grid
· Number of holes: 39
· Frontal-polar area: Fp1, Fpz, Fp2
· Anterior-frontal area: AF7, AF3, AF4, AF8
· Frontal area: F7, F3, Fz, F4, F8
· Fronto-central area: FC5, FC1, FC2, FC6
· Central area: C3, C1, Cz, C2, C4
· Temporal area: T7 (T3), T8 (T4)
· Central-parietal area: CP5, CP1, CP2, CP6
· Parietal area: P7, P3, Pz, P4, P8
· Parieto-occipital area: PO7, PO3, PO4, PO8
· Occipital area: O1, Oz, O2
Reference Code and Model Compatibility
· NE019-P-NB1.(size).WH.MD:GV: Enobio 8 / 20 / 32, Starstim tES / 8
· NE019-P-NB2.(size).WH.RU:GV: Starstim 20 / 32
· Where (size) is: 0S, 0M, 0L or XL
